Hakko 485

HAKKO CORPORATION

  • Flow soldering pot that enables pin-point heating using nozzles matching components
  • Solder that blocks holes is removed by the air unit when components are dismounted
  • Compatible with lead-free solder
  • The impeller and chamber that are most easily corroded are plated with corrosion-resistant material
Model No.485
Power consumption850W
Temperature rangeNormal temperature-300ºC
Temperature stability±2ºC
Molten solder capacity10kg
Dimensions500(W)×245(H)×550(D)mm
Weight35kg
Air Unit
Air pressure196 to 686kPa (2-7kgf/cm2)
Dimensions150(W)×100(H)×300(D)mm
Weight3.5kg

* Weight (w/o solder, cord)
* Solder is not included when factory setting.

|More Specifications



HAKKO CORPORATION

  • Flow soldering pot that enables pin-point heating using nozzles matching components
  • Solder that blocks holes is removed by the air unit when components are dismounted
  • Compatible with lead-free solder
  • The impeller and chamber that are most easily corroded are plated with corrosion-resistant material
